Criticality-Aware Instruction-Centric Bandwidth Partitioning for Data Center Applications

Static partitioning can't react quickly to load changes → use fine-grained control signals and core allocation instead

Venue: HPCA 2025
Link: Paper PDF

Topic: Hardware resource partitioning for interference isolation is too slow to react to rapidly changing workloads. A better approach uses criticality-aware control signals and fast core allocation to mitigate interference at fine granularity.

Summary

Tail latency is critical in data centers, but co-located tasks compete for shared resources (cores, memory bandwidth, LLC, execution units) causing interference. Hardware partitioning is the common solution but reacts too slowly — static assignment wastes utilization, dynamic adjustment takes tens of seconds. The key insight: core allocation can achieve performance isolation faster and more efficiently than resource partitioning, given the right control signals.

Background

Why tail latency matters

• End-to-end response times are determined by the slowest individual response.
• Data centers pack multiple tasks on the same machine to improve CPU utilization.
• Task competition for shared resources causes significant latency spikes.

Types of CPU interference

1. Hyperthreading interference (within a physical core): serious when shared execution resources are contended.
2. Memory bandwidth interference: impacts all cores sharing the same physical CPU.
3. LLC interference: impacts all cores sharing the same physical CPU.

Limitation of partitioning-based approaches

• Static partitioning: assign enough resources for peak load → poor CPU utilization.
• Dynamic partitioning: converging to the right configuration after a workload change takes dozens of seconds → misses latency spikes.
• Goal: faster reaction times while achieving both strict performance isolation and high CPU utilization.

Key Idea

Core allocation as the primary isolation mechanism

• Instead of partitioning resources → use control signals and policies to drive fast core allocation.
• Core allocation avoids the reaction-time limitations imposed by hardware partitioning mechanisms.

Challenges

1. Sensitivity: many interference types → need control signals that accurately detect each type.
2. Scalability: software overhead of gathering signals and adjusting allocations must be minimal.

Design

Dedicated scheduler core

• A centralized, dedicated core collects control signals and makes resource allocation decisions.
• Distinguishes between Latency-Critical (LC) tasks and Best-Effort (BE) tasks.
• Workflow:
  1. Collect fine-grained measurements (memory bandwidth, request processing times).
  2. Detect interference (memory bandwidth, hyperthreading).
  3. Adjust core allocations.
  4. Restrict cores from BE tasks to eliminate interference impact on LC services.

Controllers

• Top-level core allocator: grants more cores to tasks experiencing queueing delays.
• Memory Bandwidth Controller: uses available bandwidth while avoiding saturation.
• Hyperthread Controller: detects hyperthread interference → bans use of the sibling hyperthread until the current request completes.

KSCHED: Fast and Scalable Scheduling

• Linux kernel module that performs scheduling across many cores simultaneously in microseconds.
• Shifts scheduling work from the scheduler core to tasks’ cores.
• Leverages hardware multicast IPIs to amortize interrupt sending cost.
• Provides a fully asynchronous, non-blocking scheduler interface.

Insights

• Core allocation can achieve performance isolation more effectively than resource partitioning.
• Defining the right control signals (state representation) is key to handling interference tradeoffs.
