October 6, 2025

Extending Applications Safely and Efficiently

EIM model abstracts extension resources for fine-grained safety/interconnectedness tradeoffs; bpftime enforces it efficiently

Venue: OSDI 2025

Topic: Application extensions (eBPF, plugins) must balance interconnectedness vs. safety vs. isolation vs. efficiency — no existing framework achieves all four simultaneously. EIM provides a resource-based abstraction; bpftime enforces it with lightweight mechanisms.

Summary

Software extensions improve performance, add features, and enhance security — but current tools are neither safe, isolated, nor efficient enough. The core tension: fine-grained interconnectedness (extensions need to read/modify application state) vs. safety (extensions must not corrupt the host). EIM (Extension Interface Model) represents extension features as abstract resources to handle this tradeoff. bpftime is a userspace extension runtime that enforces EIM specifications using eBPF-style verification and ERIM-style intraprocess hardware isolation.

Background

Three key requirements for extension frameworks

1. Fine-grained safety/interconnectedness tradeoffs: no single definition of safety fits all use cases.
2. Extension isolation: host applications must not modify extension state.
3. Efficiency: extensions must run at near-native speed.

Prior work limitations

| Approach | Safety/Interconnectedness | Isolation | Efficiency | |—|—|—|—| | Native execution | ✗ (no tradeoff) | ✗ | ✓ | | SFI-based tools | ✗ (can’t handle tradeoff) | Partial | ✗ (runtime validation) | | Subprocess isolation | Partial (needs host code changes) | ✓ | ✗ (context-switch overhead) | | eBPF uprobes | ✗ | Partial | ✗ (kernel trap per extension entry) |

Key Idea

EIM: Extension Interface Model

• Represents each extension feature needed for interconnectedness — or restricted for safety — as a single abstraction called a resource.
• Supports fine-grained interconnectedness/safety tradeoffs per extension.
• Works as an API-like specification that bpftime enforces.

bpftime: extension runtime

• Enforces EIM specifications using lightweight techniques:
  • Safety: eBPF-style verification → 0 runtime overhead.
  • Isolation: ERIM-style intraprocess hardware-supported isolation → minimal overhead.
• Introduces concealed extension entries via binary rewriting → eliminates runtime overhead for idle extension entry points.
• Fully compatible with existing eBPF → can extend both kernel and user-space applications.

Design

EIM

• Models each extension requirement as a resource with configurable access permissions.
• Provides a principled way to balance interconnectedness and safety without requiring host code changes.

bpftime

1. Safety via eBPF verification: static analysis at load time → no per-extension-call overhead at runtime.
2. Isolation via ERIM: intraprocess memory domain isolation → extensions can’t corrupt host state.
3. Efficiency via concealed entries: binary rewriting hides extension entry points when not needed → eliminates unused entry overhead.

Questions

• How does EIM handle dynamic, runtime-determined access patterns that static verification can’t anticipate?
• Concealing extension entries requires watching idle status — does this bookkeeping overhead scale at high entry counts?

Meeting Notes

(to be filled)
