Coordinated and Efficient Huge Page Management with Ingens

Treat memory contiguity as a first-class resource; track utilization and access frequency for principled huge page management

Venue: OSDI 2016
Slides: USENIX Slides

Topic: Current OS huge page support is built on 4KB-centric assumptions and spot fixes. Ingens redesigns huge page management on two principles: contiguity as an explicit resource, and tracking spatial/temporal access patterns.

Summary

Modern processors offer dual-level TLBs with thousands of huge page entries, but OSes still manage memory assuming 4KB pages. Current huge page support in Linux causes fairness and performance pathologies: fragmentation, memory bloat, increased page fault latency, and non-swappability. Ingens manages contiguity as a first-class resource and tracks utilization and access frequency to eliminate these pathologies.

Background

Why huge pages?

• TLB misses account for up to 50% of execution time for memory-intensive workloads.
• Huge pages (2MB) replace many 4KB TLB entries with one → fewer TLB misses.
• Linux address translation traverses up to 5-level page tables; with huge pages, translation stops at level 4 → cheaper TLB miss handling.

Problems with current huge page support

1. Increased page fault latency
   • Allocating a 2MB huge page requires finding 2MB of contiguous physical memory.
   • Fragmentation forces expensive memory compaction.
   • Kernel must zero-out the entire 2MB page before giving it to a process → more time than zeroing a 4KB page.
2. Memory bloating
   • Linux allocates a huge page on every base page fault.
   • Processes receive much more memory than they actually use → increased memory footprint.
3. Fragmentation (internal and external)
   • Internal: portions of a huge page go unused.
   • External: free physical memory fragmented into small chunks → can’t form 2MB contiguous regions.
4. Not swappable/migratable
   • The kernel doesn’t support swapping huge pages directly.
   • Huge pages must be demoted to base pages before swapping → performance degradation.

Key Idea

Two principles

1. Memory contiguity is an explicit resource to be allocated across processes — not a by-product.
2. Good information about spatial and temporal access patterns is essential — allows the OS to predict when contiguity will be profitably used.

Design

Ingens framework

• Manages contiguity as a first-class resource: tracks available contiguous regions and allocates them explicitly.
• Tracks utilization (is the huge page region actually accessed?) and access frequency (how often?).
• Based on these signals, Ingens decides when to promote base pages to huge pages and when to demote huge pages back.
• Eliminates fairness pathologies by making contiguity allocation transparent and coordinated across processes.

Evaluation

• Eliminates a number of fairness and performance pathologies in memory-intensive applications with dynamic memory behavior.
• Provides better performance, memory savings, and fairness compared to Linux’s transparent huge page support.

Meeting Notes

(Note: 2016 paper — some details may be outdated given subsequent OS and hardware developments.)
