Reducing Minor Page Fault Overheads through Enhanced Page Walker

Hardware-software co-design offloads minor page fault critical path → 33× latency improvement, 6.6% runtime improvement

Venue: ACM TACO (Journal)
Link: ACM DL

Topic: Growing application memory footprints induce increasing minor page fault rates. Each fault takes thousands of CPU cycles. MFOE offloads the fault critical path to dedicated hardware and parallelizes pre-fault work in a background thread.

Summary

Minor page faults occur when a page is in physical memory but not yet mapped in the MMU for the faulting thread. As application memory footprints grow, minor page fault overhead can reach 29% of execution time. MFOE (Minor Fault Offload Engine) splits fault handling into pre-fault, critical-path, and post-fault phases:

• Pre/post-fault work is moved to a background thread.
• The critical path is executed by a per-core hardware accelerator. Result: 33× improvement in average critical-path latency, 51× improvement in tail latency, 6.6% runtime improvement on average.

Background

Minor page fault definition

• A page is loaded in physical memory but the MMU has not yet registered the mapping for the requesting thread.
• No disk I/O (no swap), but the kernel still has to find a physical frame and update page tables.
• Common case: one thread accesses a page already used by another thread in the same process.

Growing problem

• Application virtual memory footprints are growing rapidly (servers, smartphones, databases).
• More footprint → more lazy allocation → more minor page faults.
• Each minor page fault: few thousand CPU cycles, blocks the faulting thread until a free physical frame is found.
• Can reach 29% of execution time in evaluated workloads.

Key Idea

Decompose fault handling into three phases

1. Pre-fault tasks: can be done before the fault occurs → run ahead of time in a background thread.
2. Critical-path tasks: must happen during the fault → hardware-amenable → offload to MFOE.
3. Post-fault tasks: can be done after the fault → run in the background thread.

Pre/post-fault functions combined into a background thread → their latency is removed from the critical path of the faulting program.

Design

Software: parallel pre-fault page allocation

• Parallelize portions of kernel page allocation.
• A background thread runs ahead of fault time, pre-allocating physical frames.
• Multi-threaded mode considered for all applications to account for parallel fault events.

Hardware: MFOE (Minor Fault Offload Engine)

• A per-core hardware accelerator for minor fault handling.
• Maintains a pre-allocated page frame table — frames are ready to use when a fault arrives.
• On page fault:
  1. Picks a pre-allocated frame from the table.
  2. Makes a TLB entry.
  3. Updates the page table entry.
• A background kernel thread periodically refreshes the pre-allocated frame table and updates kernel data structures.

Evaluation

• Evaluated in the gem5 architectural simulator with a modified Linux kernel running on simulated MFOE hardware.
• Average critical-path fault handling latency: 33× improvement.
• Tail critical-path latency: 51× improvement.
• Application runtime: average 6.6% improvement across evaluated workloads.
