October 5, 2025

Benchmarking, Analysis, and Optimization of Serverless Function Snapshots

Functions access stable working sets across invocations → prefetch from disk to cut cold-start latency by 3.7×

Venue: ASPLOS 2022
Slides: Google Slides

Topic: Snapshotting is already used to reduce cold-start latency in serverless, but snapshot-based invocations still run 95% slower than memory-resident ones due to page faults. Functions access a stable, predictable working set → prefetch it.

Summary

Snapshot-based cold starts still suffer from frequent page faults as guest memory is loaded from disk one page at a time. Key insight: the same function accesses the same stable working set of pages across different invocations. → REAP records the working set on first invocation and proactively prefetches it for subsequent cold starts. Result: 97% reduction in page faults, 3.7× cold-start latency improvement.

Background

Snapshotting as a cold-start mitigation

• Cloud providers reduced cold-start latency by storing fully-booted function snapshots on disk.
• Faster than booting from scratch, but still significantly slower than memory-resident execution.

The remaining problem: page faults

• Firecracker lazily populates guest memory → each first access to a page raises a host page fault.
• Linux userfaultfd was used to trace memory access patterns.
• Snapshot-started functions run 95% slower on average than memory-resident ones.
• Root cause: bringing function state from disk into guest memory one page at a time.

Key Idea

Observation

Functions access the same stable working set of memory pages across different invocations of the same function.

Action

REAP (Record-And-Prefetch): a lightweight software mechanism inside the vHive-CRI orchestrator.

• Records the function’s working set on the first cold invocation from a snapshot.
• Proactively prefetches that working set from disk before subsequent cold invocations.

Design

vHive: the experimental framework

• Open-source serverless experimentation framework.
• Allows researchers to study the entire serverless stack.
• Augmented to act as a MicroManager (similar to AWS Lambda’s orchestrator).

REAP workflow

1. Record phase: On first cold invocation, trace all guest memory page faults using userfaultfd. Store the accessed page addresses as the function’s working set record.
2. Prefetch phase: On subsequent cold invocations, replay the record to prefetch pages from disk into memory before execution begins.

Why it works

• The compact, stable working set provides an excellent prefetch target.
• Eliminates the majority of page faults — particularly the slow tail of rarely-accessed pages.

Evaluation

• Benchmarks: functions from FunctionBench (representative serverless suite).
• Host OS page cache flushed before each cold invocation to simulate low-invocation-frequency production conditions.

Results:

• REAP eliminates 97% of page faults on average.
• Cold-start latency reduced by an average of 3.7×.
