October 23, 2025

Disentangling the Dual Role of NIC Receive Rings

Split Rx ring into allocation (Ax) and reception (Bx) rings → reduce I/O working set, improve throughput up to 37%

Venue: OSDI 2025
Link: USENIX OSDI ‘25

Topic: NIC Rx rings serve two functions: buffer allocation and packet reception. Their combined I/O working set often exceeds LLC capacity, degrading throughput. rxBisect separates these roles into two rings to reduce the working set without sacrificing burst absorption.

Summary

Modern NICs use per-core Rx rings sized to absorb bursts. As ring size or core count grows, the aggregate I/O working set (N×R buffers) exceeds the LLC, causing cache evictions and memory bandwidth pressure. rxBisect splits each Rx ring into an allocation ring (Ax) for empty buffers and a bisected reception ring (Bx) for packet notifications. The NIC can consume a buffer from any Ax ring to deliver a packet to any Bx ring — enabling lockless cross-core buffer sharing. Result: up to 37% throughput improvement, 11× latency reduction, and robust performance under load imbalance.

Background

How Rx rings work

• Circular arrays: software fills the tail with empty buffer pointers; NIC writes packets at the head.
• Completion rings (CR) notify software of arrivals.
• Rx ring sizes must be large enough to absorb packet bursts.

The I/O working set problem

• Per-core rings (privRing): large ring size → large working set → exceeds LLC (DDIO only allocates 2 LLC ways) → main-memory access → throughput collapse and latency spike.
• Reducing ring size: prevents burst absorption → packet loss.
• Shared rings (shRing): reduce working set, but require locking for buffer reposting and suffer under load imbalance.

Key Idea

rxBisect: separate allocation from reception

• Ax ring: small, holds empty buffers for allocation.
• Bx ring: large, receives packet notifications.
• NIC can take buffers from any Ax ring to deliver packets to any Bx ring → cross-core buffer sharing without software locks.
• Ax rings can be small (small working set); Bx rings can be large (burst absorption). Working set scales with Ax, not Bx.

Design

Design principles:

1. Separate buffer allocation from packet reception using independent Ax and Bx rings.
2. NIC offloads synchronization → lockless cross-core buffer sharing.
3. Small Ax rings keep I/O working set within LLC; large Bx rings absorb bursts.

Challenges addressed:

• Reduce total allocated buffers without sacrificing burst absorption.
• Avoid synchronization overhead.
• Remain robust under load imbalance (overloaded cores don’t block others’ buffer access).

Implementation:

• Evaluated via a DPDK-based software NIC emulator (dedicated emulator core dispatches between physical Rx rings and virtual Ax/Bx rings).
• Hardware implementation would require NIC ASIC changes.

Evaluation

• Benchmarks: NAT, load balancing (network functions), MICA key-value store.

Key results:

• Balanced load: rxBisect achieves line-rate throughput using 1/8 of buffers needed by privRing.
• MICA benchmark: up to 37% throughput improvement over emulated privRing; 18% over non-emulated privRing.
• Ring size: rxBisect achieves max throughput with only 256 Ax entries; privRing needs 4× more. Larger Bx rings don’t degrade throughput.
• Load imbalance: rxBisect maintains line-rate while shRing drops by up to 60%. Outperforms dynamic shRing by 16–20% on CAIDA trace.

Limitations

• Requires NIC ASIC changes; current evaluation uses software emulation (up to 12% lower throughput, 94% higher latency vs. non-emulated runs).
• Cross-core buffer sharing can stress memory allocators (though overhead stays below 0.2% of cycles).
• I/O working set can grow if overloaded cores consume more buffers.

Meeting Notes

(to be filled)
