Sailor: Automating Distributed Training over Dynamic, Heterogeneous, and Geo-distributed Clusters

Co-optimize resource allocation and parallelization plan for heterogeneous GPU training with accurate simulation

Venue: SOSP 2025
Link: ACM DL

Topic: Heterogeneous and geo-distributed GPU clusters offer more resources per job but introduce challenges: vast configuration spaces, inaccurate simulators, and frameworks that don’t support heterogeneous parallelization plans. Sailor addresses all three.

Summary

Using heterogeneous GPU types and geo-distributed resources gives model developers access to more GPUs per job — improving training throughput. But current systems can’t efficiently use heterogeneous resources because they:

1. Don’t co-optimize resource allocation with the job’s parallelization plan.
2. Rely on inaccurate simulators for throughput/memory estimation.
3. Use training frameworks (e.g., Megatron-LM) that don’t support heterogeneous parallelization plans.

Sailor introduces a profiler, configuration planner, simulator, and extended distributed training framework that jointly solve all three problems.

Background

Heterogeneous and geo-distributed resources

• Different GPU types (A100, V100, etc.) and different inter-node bandwidths across zones.
• More GPUs per job → higher throughput, but requires carefully planned parallelization.

Existing system limitations

1. No co-optimization: current systems optimize resource allocation and parallelization plan independently → suboptimal configurations.
2. Inaccurate simulators: existing memory footprint and iteration time estimates miss critical factors.
3. Inflexible frameworks: Megatron-LM and similar systems are slow to reconfigure and don’t support different microbatch sizes per GPU — necessary for heterogeneous plans.

Key Idea

Co-optimize resource allocation + parallelization plan

• Creates a large search space → address with:
  1. Heuristic pruning: prune based on memory footprint, GPU capacity, and scalability constraints.
  2. Dynamic programming: reuse performance estimates for subproblems to avoid redundant computation.

Accurate simulation

• Collect more signals for estimation.
• Use a principled formula to model iteration time and memory footprint for any configuration.

Heterogeneous framework

• Extends Megatron-LM to support heterogeneous parallelization plans, different microbatch sizes per GPU, fast reconfiguration, fault tolerance, and elasticity.

Design

1. Profiler: collects job information, compute node specs, and network bandwidth.
2. Configuration planner: navigates the search space, recommends configurations optimizing a user-defined objective (max throughput or min cost) under constraints (budget, min throughput).
3. Simulator: accurately models iteration time and memory footprint for any given configuration.
4. Distributed training framework: adds support for heterogeneous configs, fault tolerance, and elasticity to Megatron-LM.

Evaluation

• Evaluated on heterogeneous and geo-distributed clusters.
• Outperforms baselines in throughput and cost efficiency.

Limitations

• Heterogeneity may prevent use of high-performance collective communication libraries.
• Geo-distributed networks are prone to unpredictable jitter and packet loss.
• Parallelization strategies are optimized for homogeneous settings → may need new strategies for heterogeneous-optimized collectives.

Insights

• Leverages ML training domain properties for smart search space pruning:
  • Predictable workloads → accurate simulation.
  • Domain knowledge (memory footprint constraints) → prune the search space.
  • Throughput-only objective → simplifies optimization.
• Solid evaluation with many baselines and a well-structured motivation section.

Meeting Notes

• Existing hardware limitations are fundamental → sometimes need to modify hardware assumptions.
• Even with the same hardware, finding the right use case creates new value.
• Taking app feedback ≠ application modification.
• Fairness as a goal: showed 21.6% improvement — not necessarily high enough to be the primary contribution.
• Difficult to improve performance through resource reallocation alone in general data centers, but certain domains may benefit.
