Tile Size Selection Using Cache Organization and Data Layout
Select tile sizes that fit data working sets in cache, accounting for layout and associativity
Venue: PLDI
Slides: Google Drive
Topic: Tile size selection for loop tiling must account for cache organization (size, associativity) and data layout to maximize cache reuse and minimize conflict misses.
Summary
Loop tiling improves cache reuse for compute-intensive kernels (matrix multiply, stencils), but only when tile sizes are chosen correctly. This paper analyzes how cache organization (capacity, associativity, cache line size) and data layout (row-major vs. column-major, padding) affect optimal tile size selection. A tile size model is proposed that selects tile sizes to fit working sets in cache while avoiding conflict misses due to associativity constraints.
Background
Loop tiling
- Reorders loop iterations to access a small tile of data repeatedly → improves cache reuse.
- The tile size determines how much data fits in cache during a tile’s computation.
The selection problem
- Too small: reuse is limited, tile overhead dominates.
- Too large: working set exceeds cache capacity → frequent evictions.
- Associativity: certain tile sizes cause conflict misses even when total capacity is sufficient.
- Data layout: stride of access affects which cache lines are used → affects conflict patterns.
Key Idea
- Model the tile working set size given cache capacity, associativity, and data layout.
- Select tile sizes that fit in cache while avoiding associativity-induced conflict misses.
- Account for the actual data access stride induced by the chosen data layout.
Meeting Notes
(to be filled)
